Beskrivelse
- Power Output – 800 Watts
- Power Requirements – 115-230 Volts
- Speaker Outputs – 2 x Neutrik Speakon/Jack outputs
- Frequency Response – -3dB @ 22Hz and 25KHz
- High Instrument Input – Impedance 3.9m Ohms, input range 150mV – 20 p-p
- Low Instrument Input – Impedance 10k Ohms, input range 300mV – 405V p-p
- Line Input – Impedance 22k Ohms, input level 0dBu nominal
- DI Output – 420 Ohm balanced, Level 0dBu nominal
- Impedance – Minimum 4 Ohms
- Signal to noise- Better than 80dB (EQ flat)
- EQ – Bass +/-15dB @ 100Hz, Lo Mid +/-15dB @ 340Hz, Middle +/-15dB @ 660Hz, Hi Mid +/-15dB @ 1.6kHz, Treble +/-15dB @ 7kHz shelving
- Effects Send – Impedance 22k Ohm, Level 0dBu nominal
- Effects Return – Impedance 22k Ohms, Input Level 0dBu Nominal
- Distortion – Less than 0.5% THD
- H x W x D (mm) – 89 x 311 x 235
- Weight (kg) – 2.5
